Biogas Generator

Biogas is a renewable energy source alternative to diesel and natural gas. A biogas generator set emits lower greenhouse gases that contributes in addressing the issues of climate change.

Biogas Generator

200kVA/160kW

Slide 1
Slide 2
Slide 3
Slide 4
Slide 5
Thumbnail 1
Thumbnail 2
Thumbnail 3
Thumbnail 4
Thumbnail 5

Description

Biogas is a renewable energy source alternative to diesel and natural gas. A biogas generator set emits lower greenhouse gases that contributes in addressing the issues of climate change. Biogas also increases the service life of engine components since it produces much less carbon, nitrogen oxide, sulfur dioxide, unburned hydrocarbons and particulate matter compared to diesel.

Model YDNF-200
Rated Power (kW/kVA) 160/200
Rated Current (A) 288
Rated Frequency (Hz) 60
Rated Voltage (V) 3 Phase, 220V
Dimensions (mm) 3380 x 1800 x 2500
Weight (kg) 320

Model CA6SM3
Type Water-cooled, 4-stroke,6 Cylinder
In-line
Rated Power (kW) 240
Rated Speed (rpm) 1800
Cylinder No. 6
Bore*Stroke (mm) 126.5×166
Cooling Method Water-cooled
Oil Consumption (g/kWH) 1
Cooling Water Capacity (L) 42
Gas Consumption (m³/h) 96
Starting Method 24V DC

Brand DINGOL
Model DG274H
Rated Power (kW/kVA) 160/200
Efficiency 92.5%
Voltage Regulation ≤±1
Excitation mode Brushless, Self-Excitation
Insulation Class H

Model SMARTGEN HGM6110N
Working Voltage DC8.0V to DC35.0V
Dimensions (mm) 197 x 152 x 47
Panel Cutout (mm) 186 x 141
Working Condition Temperature:(-25~70) 9C; Humidity: (20~90)%
Weight (kg) 0.56
